CSF Universal Large Single-Pass Oil Cooler - M22 X 1.5 - 12.0L X 9.33H X 2.16W

SKU: GQPL-8371
(0)
In stock
Usually ships within 24 hours
$499.00

Got questions?
Feel free to get in touch

CSF oil coolers are much more robust, durable, and can withstand a higher peak burst rate than common brazed plate-type/stacked designs. This allows the cooler to be mounted in areas that might get high debris (front fascia, diff cooler, side vents, etc). When using a conventional oil cooler, the type of mounting locations are often not considered due to the risk of damage. The CSF oil cooler is designed to withstand a tremendous amount of vibration and debris. You can even stand on it!
  • Overall Dimensions (including fitting bosses): 12.0" L x 9.85" H x 2.36" W (305mm x 250mm x 60mm)
  • 2-Year Limited Warranty
  • Core Dimensions: 9.25" L x 9.33" H x 2.16" W (235mm x 237mm x 55mm)
  • High Efficiency & Rugged Durability Bar/Plate Design
  • "Aero-Flow" Bar Design for Lightweight, Strength, and Maximum Flow
  • M22 x 1.5 Inlet/Outlet Connections
  • Two 1/8 NPT Ports on each tank for bleeding or temperature sensors
  • Satin Black Finish for Extreme Protection Against Corrosion and Debris
  • Pressure Tested at 120psi
  • Fluid Capacity: 1.5L (1.6 qt)

Attributes:

  • Brand Name: CSF Cooling - Racing & High Performance Division
  • GTIN: 00710353083710
  • Cable Included: No
  • Color: Black
  • Core Charge Applicable: No
  • Core Color: Black
  • Core Height: 237mm
  • Core Material: Aluminum
  • Core Row Quantity: 1
  • Core Thickness: 55mm
  • Core Tube: No
  • Core Type: Bar-and-Plate
  • Core Width: 235mm
  • Finish: Powder Coat
  • Fluid Capacity: 1500cc
  • Grade Type: Performance
  • Inlet Fitting Type: M22 x 1.50 female threaded
  • Inlet Gender: Female
  • Installation Type: Universal Cooling Product
  • Mounting Hardware Included: No
  • Outlet Fitting Gender: Female
  • Outlet Fitting Type: M22 x 1.50 female threaded
  • Strap Included: No
  • Tube Included: No

Extended Information:

  • Country of Origin: CN
  • Emissions : 4

Packing Information:

  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 15 x 5 x 14 inches
  • Weight: 10 POUNDS
